- Extender Cards
Client Need:
Required a method to conduct testing of Compact PCI format circuit card assemblies. Unit is "Hot Swap" capable allowing dual redundant systems to remain available during repair.
3-D Engineering Solution:
3-D Engineering composed a high power capacity extender card that allowed in-situ testing and debug while in the system providing full access to all signals.
Results:
3-D Engineering designed/produced a 6U x 160mm front and 6U x 80mm rear Extender Card that can be used for testing and support up to 32 and 64 bit transfers.
- Solder Side Cover Modifications (custom)
Client Need:
Customer needed a customized cover that would allow pins on the printed circuit board to remain intact and not bent when inserting/exerting into the chassis system.
3-D Engineering Solution:
3-D Engineering composed a tooling customized to each customer that would allow die cutting and part marking on each solder side cover. With their experience and knowledge, our engineers would go through the design phase and provide First Articles to customers before production.
Results:
3-D Engineering designed/produced a 6U x 160mm front and 6U x 80mm rear Solder Side Cover that could be customizable to each clients need.
